4 Inch EMT Coupling Electro Galvanized Blue Silver Color Plated UL Listed

China 4 Inch EMT Coupling Electro Galvanized Blue Silver Color Plated UL Listed supplier
4 Inch EMT Coupling Electro Galvanized Blue Silver Color Plated UL Listed supplier 4 Inch EMT Coupling Electro Galvanized Blue Silver Color Plated UL Listed supplier 4 Inch EMT Coupling Electro Galvanized Blue Silver Color Plated UL Listed supplier 4 Inch EMT Coupling Electro Galvanized Blue Silver Color Plated UL Listed supplier 4 Inch EMT Coupling Electro Galvanized Blue Silver Color Plated UL Listed supplier 4 Inch EMT Coupling Electro Galvanized Blue Silver Color Plated UL Listed supplier 4 Inch EMT Coupling Electro Galvanized Blue Silver Color Plated UL Listed supplier

Large Image :  4 Inch EMT Coupling Electro Galvanized Blue Silver Color Plated UL Listed

Product Details:

Place of Origin: Hangzhou,China
Brand Name: RANLIC
Certification: UL E350597
Model Number: RL-610

Payment & Shipping Terms:

Minimum Order Quantity: 2000 Nos
Price: negotiation
Packaging Details: inner cartons with main cartons
Delivery Time: 20 DAYS
Supply Ability: 100000 Pieces / 10 days
Contact Now
Detailed Product Description
Material: Steel Locknut: Steel Locknut
FInish: Electro-Gal. Thread: NPT
UL File No.: E350597 Type: Set-Screw
Brand: RanLic
High Light:

NPT Thread 4 Inch EMT Coupling

,

Electro Galvanized EMT Coupling

,

UL Listed EMT Coupling

4" EMT Steel Coupling Electro Galvanized Blue Silver Colore Plated UL Listed 25 pcs Per Package



General:

As UL stipulated:all the sizes need to be using corresponding item code when we appliedd the UL, C/W screw and steel locknut

EMT steel Connector

American Standard, NPT Thread

UL Standard 514B

Size: 1/2" to 4"
Material: Steel

RANLIC steel emt connectors are used to bond EMT conduit to electrical junction boxes or enclosures. RANLIC EMT steel connectors provide concrete tight connections when taped and properly secured with the included locknut, and are rated for electrical applications above 600 volts. Their heavy gauge steel construction maintains mechanical protection and solid grounding of the conduit to the designated electrical junction box or enclosure. Additionally, EMT conduit connectors are pure steel and zinc plated for excellent corrosion protection.



Features:

 RANLIC UL listed emt connectors is the adaptor for connction of  EMT conduit to steel outlet boxes or enclosures.RANLIC UL LISTED EMT connectors provide concrete tight connections when taped and properly secured with the included locknut, and are rated for electrical applications above 600 volts. Their heavy gauge steel construction maintains mechanical protection and solid grounding of the conduit to the designated electrical junction box or enclosure.Our EMT connector each lot of zinc alloy will be testing in the factory to assure the material stable quality

UL Standard 514B our UL file number is E350597, You may browse UL.COM to check our file number

Size: 1/2" to 4"



Applications:

EMT steel connector: Joins steel EMT conduit to Electrical box and enclosure

• Connect & effectively bond EMT conduit to steel outlet boxes, load centers & other metal enclosures
• May be used indoors and in concrete-tight applications when taped
• Body and locknut made with die-cast zinc alloy
• Set screw made with zinc-plated steel
• Tri-Drive screw head design for use with Phillips, slotted and square screwdrivers
• Screw thread is designed to not vibrate loose
• Reversible locknut designed to cut through protective coatings on boxes & enclosures
• UL standard for safety
• Application type : EMT
• Electrical Product Type : Standard Fitting
• Fitting type : Connector
• Indoor/Outdoor : Indoor
• UL File No.:E350597
• Material: steel



Trade Size: Outside Diameter(1) Inside Diameter(2) wall thick
US Metric in. mm in. mm Standard thin
1/2" 16 0.706 17.93 0.622 15.8 1.07 0.85
3/4" 21 0.922 23.42 0.824 20.93 1.25 1.05
1" 27 1.163 29.54 1.049 26.64 1.45 1.15
1-1/4" 35 1.51 38.35 1.38 35.05 1.65 1.3
1-1/2" 41 1.74 44.2 1.61 40.89 1.65 1.3
2" 53 2.197 55.8 2.067 52.5 1.65 1.3
3" 78 3.5 88.9 3.356 85.24 1.83 1.8
4" 103 4.5 114.3 4.334 97.38 2.11 2.1





Why Choose RANLIC steel emt connector:



1) As the factory always can make shipment ontime
2) Prices always keep competitive

3) Our prices always keep for whole year

4) UL listed always keep high quailty



Finished steel connector:



4 Inch EMT Coupling Electro Galvanized Blue Silver Color Plated UL Listed









4 Inch EMT Coupling Electro Galvanized Blue Silver Color Plated UL Listed
