Electrical BS31 Class 3 and Classs 4 Gi Conduit Pipe 4" and 3.75M Length

China Electrical BS31 Class 3 and Classs 4 Gi Conduit Pipe 4" and 3.75M Length supplier
Electrical BS31 Class 3 and Classs 4 Gi Conduit Pipe 4" and 3.75M Length supplier Electrical BS31 Class 3 and Classs 4 Gi Conduit Pipe 4" and 3.75M Length supplier Electrical BS31 Class 3 and Classs 4 Gi Conduit Pipe 4" and 3.75M Length supplier

Large Image :  Electrical BS31 Class 3 and Classs 4 Gi Conduit Pipe 4" and 3.75M Length

Product Details:

Place of Origin: HANGZHOU,CHINA
Brand Name: RANLIC
Certification: ISO9001
Model Number: RL16-BS10

Payment & Shipping Terms:

Minimum Order Quantity: 1*20gp container
Price: negotiation
Packaging Details: 100 lgths/Bundle
Delivery Time: 15
Supply Ability: 3000 TONS/MOUNTH
Contact Now
Detailed Product Description
C/W: Socket & Plastic Cap Material: Carbon Steel Coil
Type: Class 3 &Class 4 Size:: 3/4" To 4"
Color: Gray White Thread: BS31 Standard
Thickness: 1.25mm To 1.60mm Gal.Thick: 15 Micrometer Class 3



GI Electrical BS31 Conduit Class 3 and Classs 4 With Maximum Size Up to 4" and 3.75meters length



General:

Steel BS31 G.I. conduit is manufactured from a mild steel tube,It has an accurate circular cross section,a uniformand wall thickness,a defect free interior surface.The finished threads,BS4568,conforms to the BS31 1940 ,Each length of the conduit have the size,logo,product name print or engraved to make as installation instructions



Application:

Ranlic BS31 conduit can be installed indoors or outdoors,in dry or wet locations,exposed or concealed,in all kinds of atmospheric conditions if use the standared thickness,the galvanized thickness exceeding 70 micro meter.it provides excellent mechanical protection for the conductors while reducing Electro-Magnetic Field exposure and shielding.



Features:

Q195 steel coil for mechanical strength,well controled internal beads(all can remove as seamless) essential for wire pulling and resistant to snagging The conduits are come with a coupler screwed on one end and a protective plastic cap at the other ends to prevent damage.Rigorous quality control procedures to ensure process and product consistency

  • Galvanized steel construction provides shielding from magnetic fields and protection from impact damage and crushing
  • Electroplated couplings prevent zinc build-up
  • Designed for use with threaded connections
  • Brand Name: RANLIC
  • Length : 3.75 meters.
  • Material : Galvanized steel-class 3 / Hot-dipped Galvanized-class 4
  • Size: 3/4”-4"
  • Thickness: 1.3mm---1.6mm or according to customer's requirement



Characteriestic & Diamention:

NORMAL ITEM No. OUTSIDE DIAMETER NORMAL  THIN WALL  LENGTH W/O SMALL  BIG
SIZE MIN MAX THICKNESS THICKNESS COUPLING PKG (LGTHS) PKG (LGTHS)
3/4" RL16-BS10 18.9mm 19.05mm 1.60mm±0.15mm 1.30mm 3.75 meters 10 100
1" RL16-BS11 25.2mm 25.40mm 1.60mm±0.15mm 1.30mm 3.75 meters 10 100
1-1/4" RL16-BS12 31.6mm 31.75mm 1.60mm±0.15mm 1.45mm 3.75 meters 10 50
1-1/2" RL16-BS13 37.5mm 38.10mm 1.80mm±0.15mm 1.60mm 3.75 meters 5 30
2" RL16-BS14 50.0mm 50.80mm 1.80mm±0.15mm 1.60mm 3.75 meters 5 30
2-1/2" RL16-BS15 72.0mm 72.57mm 3.81mm±0.20mm 1.80mm 3.75 meters 1 5
3" RL16-BS16 88.15mm 88.29mm 3.81mm±0.20mm 2.10mm 3.75 meters 1 5
4" RL16-BS17 113.0mm 113.44mm 3.81mm±0.20mm 2.10mm 3.75 meters 1 5



Why Choose Ranlic Conduit Item:

1) High quality material ensures a finish conduit and fittings with superior properties
2) Manufactured by perfect molds and professtional engineer
3) Fitted perfectly with fittings(conduits) for the CNC threading machine
4) 10 years export experience to make sure the perfect shipment date and package
5) Always like to listening customers feedback for the conduit arrived to
   customer's warehouse to improving our service



Our Package:

Electrical BS31 Class 3 and Classs 4 Gi Conduit Pipe 4" and 3.75M Length
